Diezel VH4 Amp
| |
|
| Specifications
|
|
|
Model: |
VH4 |
|
Output Power: |
90-160W |
|
Channels: |
4 |
|
Loops: |
4 channel
inserts, serial and parallel master loops |
|
Equalization: |
bass, mid
treble in each channel, deep and presence in the master section |
|
Pre-Amp: |
4 individually
voiced, all tube pre- amps. Clean, crunch, heavy and lead |
|
Power-Amp: |
Monaural
4-tube power amp section. Accepts 6L6, EL34, 5881, 6550, KT66, etc. |
|
Dimensions: |
29"x11"x11" |
|
Weight: |
50lbs |
Diezel Amp Features / Sounds /
Advantages
The
100-watt Diezel VH4 features four independent channels, each with its
own Gain, Volume, Treble, Mid, and Bass controls. You can set the tone
of each channel exactly the way you like it. There is no frustrating "EQ-sharing"
on this amp. If you want the ultimate in tonal flexibility and
versatility as well as superb sound quality, the VH4 has no equal. The
VH4 also features six effects loops: an individual loop for each channel
that is programmable, a master parallel loop with a mix level control,
and a master serial loop which is also programmable. This VH4 has four
Electro-Harmonix EL-34 tubes for the best balance of midrange warmth and
sweet highs as well as defined lows.
The Diezel VH4 is an
all-tube amp with four individual preamps, integrated midi-switcher and
. . . .
The Diezel Clean
channel is one of the best in the industry, with plenty power and lots
of percussive, piano like punch.
The Diezel Crunch
channel is very pleasing for bluesy play or with less gain to resemble a
vintage clean tone. Crank the gain up and it becomes a nice broad and
open crunch a'la AC/DC.
The third channel (Diezel
Heavy) is simply unbelievable. It has big dynamic ranges, from
playful little licks, tasty solo work, to all out metal gain. The tone
will not lose definition, though. Even at high gain selections, with
humbucker guitars, it speaks straight from the artist's fingers. This
channel is easy to play for the intuitive. It cleans up with guitar
volume rolled off, and then comes on like a freight train when needed.
Diezel Channel four
starts where three leaves off. If gain is your thing, then channel four
is sure to please you. It compresses more than three, retains definition
to a large degree, and just shreds with big bass and strong high end. It
is smooth distortion, creamy but authoritive. Very Loud.
The power stage of the
Diezel VH4 is either mono or stereo, depending on which model you
choose. VH4 is the mono amp, VH4S has stereo power and stereo effects
returns. The circuit accepts 6L6, KT66, KT88, 6550, 5881, and with the
flick of a switch also EL34 Power tubes. Biasing is simple and quick.
The amp likes 35mA biasing current for matched tube sets. Each tube has
a tube fault indicator, and a separate fuse. In case of tube failure,
the fuse blows and takes the duet out of the circuit. You will finish
your set with two tubes, instead of a dead amp.
The power amp has a
master volume, presence and deep controls. There are parallel and serial
returns to the power amp. Two sends give you flexibility far beyond any
standards. One of the sends is front panel/midi switchable. The parallel
return has a mix control on the front panel in the master section. Oh,
not to forget the channel inserts for channel one through four. These
can be manually or midi controlled. The Diezel Midi system has 16
channels, with 128 program changes.
$4,599.00
- Due to Very Limited
Availability, This Amp is Pre-Order Only. We simply cannot keep
them in stock, They are HOT!
|
